商品規格:

  • Digital section:
  • D/A converter: 24 bit/192 kHz
  • Sample rate converter: 24bit / 192kHz
  • Inputs: SPDIF, 2x Toslink, 1x USB
  • USB: asynchronous up to 24bit/ 192kHz supported
  • SPDIF:24bit/ 192kHz
  • Toslink:24bit/ 96kHz
  • Streamer section:
  • Advanced 802.11 AC WiFi with MIMO
  • 1x Gigabit Ethernet (1000Mbps)
  • 1x USB for external storage
  • iOS, Android and web app
  • Streaming services:
  • Spotify Connect
  • TIDAL
  • WiMP
  • Qobuz
  • AirPlay
  • Internet Radio
  • DLNA as renderer
  • Supported formats:
  • All popular formats including: WAV/WAVE, MP3, AAC+, Vorbis, AC3, DTS, ALAC, FLAC, APE, WMA, up to 192kHZ/24bit, DSD, up to DSD 128 (5.6 MHz)
  • Preamplifier section
  • Input impedance ( Balanced input ): 47Kohm
  • Maximum input level: 10 Volt RMS
  • Noise floor ( 1Vrms, 20 – 20 kHz, balanced)
    -135 dB
  • THD + N (1Vrms, 20 – 20 kHz, balanced) : <0.004%
  • Gain (Balanced): 0 dB
  • Amplifier section:
  • Output Impedance: 120 dB
  • THD ( 20 – 20 kHz): 100A
  • Damping factor 8 ohm load: >350
  • I Input sensitivity 120W output: 1.3Vrms
  • Input sensitivity HT 120W output: 1Vrms
  • Gain HT Input: x36 (31 dB)
  • Rated output power:
  • 8 ohms: 2 x 125 W
  • 4 ohms: 2 x 200 W
  • 2 ohms: 2 x 370 W
  • Power consumption
  • 110 W
  • Standby: 1W
  • Dimensions:
  • Width: 465 mm / 18.3 inches
  • Depth: 405 mm / 16 inches
  • Height: 128 mm / 5 inches
  • Weight: 20Kg / 44 lbs.
